High-Quality Stainless Steel Construction Decoration Material Galvanized Steel Pipe From Factory

Großes Bild : High-Quality Stainless Steel Construction Decoration Material Galvanized Steel Pipe From Factory

Produktdetails:

Herkunftsort:	China
Markenname:	qijie
Zertifizierung:	steel pipe
Modellnummer:	Stahlrohr

Zahlung und Versand AGB:

Min Bestellmenge:	10 Tonnen
Verpackung Informationen:	Schüttgut
Lieferzeit:	15-18 Tage
Zahlungsbedingungen:	L/C, D/P, T/T, Western Union
Versorgungsmaterial-Fähigkeit:	100tons

Kontakt

Ausführliche Produkt-Beschreibung

Material:

Stahl

Oberflächenbehandlung:

feuerverzinkt

Standard:

GB/T3091 – 2001, BS1387 – 1985, DIN EN10025, EN10219, JIS G3444:2004, ASTM A53

Stahlsorte:

GB/T3091 – 2001:Q195, Q235 BS1387 – 1985, DIN EN10025 EN10219: S235JR JIS G3444:2004: STK400 ASTM A5

Hervorheben:

stainless steel galvanized pipe

construction decoration steel pipe

factory galvanized steel mesh

High-Quality Stainless Steel Construction Decoration Material Galvanized Steel Pipe From Factory

Hot dip galvanized tube is to make molten metal and iron matrix reaction and produce alloy layer, so that the matrix and coating of the combination of the two. Hot dip galvanizing is the first steel pipe pickling, in order to remove iron oxide on the surface of the steel pipe, pickling, through ammonium chloride or zinc chloride aqueous solution or ammonium chloride and zinc chloride mixed aqueous solution tank for cleaning, and then into the hot dip plating tank. Hot dip galvanizing has the advantages of uniform coating, strong adhesion and long service life. Complex physical and chemical reactions occur between hot dip galvanized steel tube and molten plating solution to form a tightly structured zinc-ferroalloy layer with corrosion resistance. The alloy layer is integrated with pure zinc layer and steel tube matrix, so its corrosion resistance is strong.

Quick Details

Standard	ASTM, GB, JIS, DIN,BS, ASTM A106-2006, ASTM A53-2007, ASTM A 53M-2007, ASME B36.10M-2004, GB /T 3091-2001, GB/T 13793-1992, JIS J3444-2006, JIS J3466, DIN 2444,BS 1387, BS 1139, BS 4568, BS EN 39	Grade	Q195-Q345, A53-A369, ST35-ST52, 10#-45#, Q235, Q345, Q195, Q215,A53(A,B), A106(B,C), ST 42, 10#, 20#
Thickness	1MM - 10MM	Section Shape	Round
Outer Diameter	21.3 MM - 273 MM	Place of Origin	Tianjin, China
Application	Structure Pipe	Technique	ERW
Certification	ISO9001 ISO18001 UL	Surface Treatment	Galvanized or Painted or Black
Special Pipe	Thick Wall Pipe	Alloy Or Not	Non-Alloy

Tolerance	±5%	Type	Weld Steel Pipe
Processing Service	Bending, Welding, Punching, Cutting	Product Name	Pipe, Tube
Secondary or Not	Non-secondary	Length	As Customers' Requirement
Material	Carbon Steel (Q195, Q235, Q345)	Zinc Coating	220 g/m2 ( or Customized)
Pipe Ends	Plain, Bevel, Threaded or Grooved	End Protector	None or Plastic Caps

2. Chemical Composition

Grade	Chemical Composition					Mechanical Properties
	C	Mn	Si	S	P	Yield	Tensile	Eelongation
	C	Mn	Si	S	P	Strength Mpa	Strenth Mpa	%
Q195	0.06-0.12	0.25-0.50	≤0.30	≤0.045	≤0.05	≥195	315-430	≥33
Q215	0.09-0.15	0.25-0.55	≤0.30	≤0.05	≤0.045	≥217	335-450	≥27
Q235	0.12-0.20	0.30-0.67	≤0.30	≤0.045	≤0.04	≥235	375-500	≥26
Q345	≤0.20	1.00-1.60	≤0.55	≤0.04	≤0.04	≥345	470-630	≥22

1.Black square&rectanhgular steel pipe:ERW steel tube
2.Pre-galvanized square&rectangular steel pipe: Pre-galvanized square/rectangular tube is made of hot dipped galvanized steel strip directly.
3.Hot dipped galvanizedsquare&rectangular steel pipe : Hot dipped galvanized square/rectangular tube owns thicker zinc coating than pre-galvanized square/rectangular tube. Black tubes will be dipped into zinc pool for galvanizing.
4.Electro galvanized square&rectangular steel pipe : The technology of electro galvanized square/rectangular tube is similar to hot dipped galvanized tube, but the thickness of zinc coating is less than hot dipped galvanized tube.
5.Painted square&rectangular steel pipe:Painted square/rectangular to remove the rust and clean the oil first and then paint the required color paint.
Standard:GB/T6728:2002,ASTMA500,JIS G3466,EN10210,EN10219
Steel Grade:
GB/T6728:2002 : Q195 , Q235 , Q345
ASTM A500:GR. A , GR. B, GR. C , GR. D
JIS G3466 : SS440,SS540
EN10210, EN10219: S235JR ,S275JR,S355JR, S355J2H

Square & rectangular steel tube : The size can be based on your requirement to custom.

Name	Size	Wall Thickness	Length
Name	mm	mm	m
Square tube	10x10-500x500	0.6-25.0	1-12m
Rectangular tube	20x10-200x400	0.7-13.0	1-12m

TECHNICAL PARAMETERS
Product Name	Galvanized Steel Round Pipe
Keywords	Steel Pipe
Standard	BS1139-1775, EN1039, EN10219, JIS G3444:2004, GB/T3091-2001, BS1387-1985, DIN EN10025, ASTM A53 SCH40/80/STD, BS-EN10255-2004
Material	Q235, Q345, S235JR, S275JR, STK400, STK500, S355JR, GR.B-D
Thickness	Pre Galvanized:0.6-1.5mm.
Thickness	Hot Dipped Galvanized: 1.6- 25mm.
Length	5.80 Meters Or 6 Meters As Usual Or By Customer'S Requirements
Out Diameter	Pre Galvanized:1/2''-4''(21.3-114.3mm).
Out Diameter	Hot Dipped Galvanized:1/2''-10''(21.3Mm-273.1mm).
Zinc Coating	Pre Galvanized:5GSM-40GSM
Zinc Coating	Hot Dipped Galvanized 35GSM-200GSM
Technique	Electronic Resistance Welded (ERW)
Surface Finish	Pre-Galvanized, Hot Dipped Galvanized, Electro Galvanized, Black, Painted, Threaded, Engraved, Socket.
Application	Hot Dipped Galvanized Steel Pipe Is Widely Used In Construction, Structure, Accessorize,Construction, Machinery Parts,Fluid Transportation,The Stress Parts Of The AutomobileTractor Parts And So On.
Packing	1.Big OD:In Bulk
	2.Small OD:Packed By Steel Strips
	3.Woven Cloth With 7Slats
	4.According To The Requirements Of Customers

SIZE INTRODUCTION
Out Diameter	Wall Thickness	Length
Inch	Mm	M
1/2"	0.5-2.75	1-12M (Customized)
3/4"	0.5-2.75	1-12M (Customized)
1"	0.5-3.75	1-12M (Customized)
1-1/4"	0.5-5.0	1-12M (Customized)
1-1/2"	0.5-5.0+	1-12M (Customized)
2"	0.5-5.0+	1-12M (Customized)
2-1/2"	0.8-5.0+	1-12M (Customized)
3"	0.8-5.0+	1-12M (Customized)
4"	0.8-4.0	1-12M (Customized)
5"	1.1-4.75	1-12M (Customized)
6"	1.1-6.0+	1-12M (Customized)
8"	1.2-6.5+	1-12M (Customized)
10"	2.75-5.0+	1-12M (Customized)
